Interactive Training Interface | SC-IPT 4016
The Interactive Training Interface SC-IPT 4016 is a PC-connected bench unit for blended-learning experiments. It combines 4-channel measurement, 10 MHz oscilloscopes, signal generation, three-phase and DC power supplies, and 16-channel digital I/O with USB and WLAN connectivity.
The Interactive Training Interface SC-IPT 4016 is a PC-connected unit for blended-learning experiments. It combines measurement, signal generation, power supply, and digital I/O in one bench housing. This interactive training interface is an open-architecture system that accepts interchangeable experiment cards and modules.
Product Overview
The SC-IPT 4016 interactive training interface uses a 32-bit ARM processor with internal memory for measurement data. It connects by USB 2.0 and WLAN 2.4 GHz (802.11 b/g/n), and supports multiple experiment modules at once. Four differential analogue inputs sample at 100 MSa/s with 10 MHz bandwidth. Two current inputs with 5 A overcurrent protection and three variable analogue outputs are included. Sixteen digital outputs, sixteen digital inputs, and eight relay outputs are provided. Virtual instruments include voltmeters, ammeters, a power meter, a multimeter, and 2- and 4-channel oscilloscopes at 10 MHz. Spectrum analysis and Bode plotting are included. Signal generation covers DC, function, arbitrary, and pulse sources. Power supply functions include three-phase and adjustable DC sources. Control software runs on Windows 10/11 (64-bit) under a perpetual site licence. PC and course software are separate items.
Interactive Training Interface SC-IPT 4016 — Technical Specifications
| Parameter | Value |
|---|---|
| Tender Item ID | 11001 |
| Model No. | SC-IPT 4016 |
| Item Code / CIC | TTS / EEE |
| Brand / Origin | Scientico / India |
| Processor | 32-bit ARM with internal memory |
| USB Interface | USB 2.0, 12 Mb/s and above |
| Wireless Interface | WLAN 2.4 GHz, IEEE 802.11 b/g/n |
| Analogue Output | 1 programmable, ±10 V, 0.2 A, DC to 5 MHz |
| Analogue Differential Inputs | 4 inputs, 10 MHz bandwidth, 100 V max, 100 MSa/s, 10-bit |
| Current Inputs | 2 inputs, 5 A overcurrent protection, 250 kSa/s, 12-bit |
| Variable Analogue Outputs | 3 outputs, ±20 V, 1 A, DC to 150 Hz |
| Digital Outputs | 16 channels, TTL/CMOS, 0 to 100 kHz, ±15 V |
| Digital Inputs | 16 channels, TTL/CMOS, 0 to 100 kHz, ±15 V |
| Relay Outputs | 8 relays, 24 V DC / 1 A |
| Oscilloscopes | 2- and 4-channel, 10 MHz |
| Spectrum Analyser | 3 Hz to 1 MHz |
| Bode Plotter | 1 Hz to 5 MHz, with locus diagram |
| Function Generator | 0.5 Hz to 5 MHz, 0 to 10 V |
| Three-Phase Supply | 0 to 150 Hz, 0 to 14 Vrms, 2 A |
| Adjustable DC Supply | 3 x (-20 V to +20 V), 2 A |
| Construction | Robust housing, DIN A4 panel compatible, 2 mm / 4 mm safety sockets, LED status |
| Software | Windows 10/11 (64-bit), perpetual site licence |
Technical Data
Processing and Connectivity:
- 32-bit ARM processor with internal measurement memory
- USB 2.0 and WLAN 2.4 GHz connection
- Simultaneous connection of multiple experiment modules
- Bus connection for experiment cards and further units
Measurement:
- 4 differential analogue inputs: 10 MHz bandwidth, 9 ranges, 4 x 8 k sample memory
- 2 current inputs: 2 ranges, 12-bit resolution
- Digital inputs: 16-bit x 2 k memory
Signal Generation and Output:
- 1 programmable analogue output: ±10 V, 0.2 A
- 3 variable analogue outputs: ±20 V, 1 A
- 16 digital outputs and 8 relay outputs
Power Supply:
- Three-phase supply: 0 to 150 Hz, 0 to 14 Vrms, 2 A
- Adjustable DC supply: 3 x (-20 V to +20 V), 2 A
Key Features
- Integrated Bench: Measurement, signal generation, power supply, and digital I/O in one housing
- Virtual Instruments: Voltmeters, ammeters, power meter, multimeter, and relay VI
- Virtual Oscilloscopes: 2- and 4-channel, 10 MHz, with cursors and XY/XT display
- Frequency Analysis: Spectrum analyser and Bode plotter with locus diagram
- Open Architecture: No proprietary bus or connector platform required
- Wireless and USB: WLAN and USB 2.0 connectivity
Experiments
- Blended-learning measurement experiments
- Oscilloscope and signal analysis
- Frequency response analysis with Bode plotting
- Spectrum analysis
- Digital I/O experiments
- Power supply and three-phase circuit experiments
- Signal generation and function generator experiments
Construction and Design
The SC-IPT 4016 uses a robust housing sized for DIN A4 training panels and equivalent modules. Measurement and output connections use BNC and 2 mm safety sockets. LED indicators show status. An experiment unit link couples experiment cards to the interface or to further units.
Software
Control software for Windows 10/11 (64-bit), supplied under a perpetual site licence for all workstations in the room, with no recurring fee. PC and course software are separate items.
Scope of Delivery
- 1 Interactive training interface SC-IPT 4016
- 6 Shunt resistors (2 x 1 ohm, 2 x 10 ohm, 2 x 100 ohm)
- 28 x 2 mm connection cables, assorted lengths and colours
- 1 Power supply and power lead
- 1 USB cable
- 1 Basic software media
- 1 Operating manual (English)
Q: What does the SC-IPT 4016 combine in one unit?
A: It combines measurement, signal generation, power supply, and digital I/O functions in one bench housing.
Q: How does the SC-IPT 4016 connect to a computer?
A: It connects by USB 2.0 or WLAN 2.4 GHz (802.11 b/g/n).
Q: Which software is supplied with the SC-IPT 4016?
A: Control software for Windows 10/11 (64-bit) is supplied under a perpetual site licence. PC and course software are separate items.
Q: Does the SC-IPT 4016 require a proprietary bus?
A: No. It uses an open architecture with no proprietary communication bus or connector arrangement.
