Lyophilizer SCI 531
The Lyophilizer SCI 531 is a freeze dryer for serum bottles, vials, ampoules, and small glassware. It offers 3 L or 6 L capacity, a 316 stainless steel chamber, and mechanical condenser cooling at -50°C or -80°C. A solid-state controller with dual digital displays and quick-seal manifold ports support controlled lyophilization.
The Lyophilizer SCI 531 is a freeze dryer for lyophilizing samples in serum bottles, vials, ampoules, and other small glassware. It is available in 3 L and 6 L capacities.
Product Overview
The Lyophilizer SCI 531 freeze dryer uses a 316 stainless steel chamber with a powder-coated G.I. sheet outer body. A mechanical cooling system maintains condenser temperature at -50°C or -80°C. A solid-state controller with dual digital displays shows set and condenser temperatures. Stainless steel manifolds provide maximum vapour flow. Each 3/4 inch port has a quick-seal valve for attaching flasks. Manifold options include drum type, vertical type, or straight type. The unit ships with a suitable vacuum pump.
Lyophilizer SCI 531 — Technical Specifications
| Parameter | Value |
|---|---|
| Capacity | 3 L or 6 L |
| Chamber Material | 316 stainless steel |
| Outer Body | G.I. sheet, powder-coated |
| Condenser Temperature | -50°C or -80°C |
| Cooling System | Mechanical |
| Vacuum Gauge Range | 1 to 30 inHg |
| Temperature Controller | Solid-state, dual digital display |
| Manifold Options | Drum, vertical, or straight |
| Port Size | 3/4 inch with quick-seal valve |
| Vacuum Pump | Suitable pump included |
Technical Data
Chamber:
- Material: 316 stainless steel
- Capacity: 3 L or 6 L
Condenser:
- Mechanical cooling system
- Temperature: -50°C or -80°C
Vacuum System:
- Vacuum gauge range: 1 to 30 inHg
- Suitable vacuum pump included
Controls:
- Solid-state temperature controller
- Dual digital displays for set and condenser temperature
Manifold:
- Stainless steel
- Options: drum type, vertical type, or straight type
- Ports: 3/4 inch, each with quick-seal valve
ey Features
- Chamber Build: 316 stainless steel chamber with powder-coated outer body
- Condenser Cooling: Mechanical system at -50°C or -80°C
- Capacity Options: 3 L or 6 L
- Vacuum Monitoring: Gauge reads 1 to 30 inHg
- Temperature Control: Solid-state controller with dual digital displays
- Flexible Manifold: Drum, vertical, or straight type
- Quick-Seal Ports: 3/4 inch ports for attaching flasks
Experiments
- Lyophilization of samples in serum bottles
- Lyophilization of samples in vials
- Lyophilization of samples in ampoules
- Freeze drying of samples in small glassware
- Condenser temperature effect on drying (-50°C vs. -80°C)
- Manifold type comparison (drum, vertical, straight)
- Capacity comparison (3 L vs. 6 L)
- Vacuum level monitoring during drying
Construction and Design
The Lyophilizer SCI 531 has a 316 stainless steel chamber inside a powder-coated G.I. sheet outer body. Stainless steel manifolds allow maximum vapour flow and easy access to all parts. Each 3/4 inch port has a quick-seal valve. A mechanical cooling system chills the condenser. The solid-state controller displays set and condenser temperatures.
Scope of Delivery
- 1 Lyophilizer unit
- 1 Suitable vacuum pump
Q: What sample containers can the Lyophilizer SCI 531 process?
A: It is designed for lyophilizing samples in serum bottles, vials, ampoules, and other small glassware.
Q: What capacity options are available for the Lyophilizer SCI 531?
A: The unit is available in 3 L and 6 L capacities.
Q: What condenser temperatures does the Lyophilizer SCI 531 reach?
A: The mechanical cooling system provides -50°C or -80°C, depending on the model selected.
Q: What manifold types are available for the Lyophilizer SCI 531?
A: You can select a drum type, vertical type, or straight type manifold.
Q: What vacuum range does the Lyophilizer SCI 531 display?
A: The vacuum gauge reads from 1 to 30 inHg.
