Equilibrium of a Beam | FortiTestX – 52
Equilibrium of a Beam – FortiTestX – 52 is a magnetic attachment kit that demonstrates forces, moments and reactions in rigid beam structures. Compatible with the Work Panel (FortiTestX – 53), this apparatus allows students to measure reaction forces in simply-supported and balanced beam configurations. Using adjustable masses and spring balances, students compare measured values against theoretical predictions from equilibrium equations. Ideal for hands-on statics education with full user guide and five-year warranty included.
Equilibrium of a Beam – FortiTestX – 52 is a hands-on kit designed for statics education using the Work Panel (FortiTestX – 53). This apparatus allows students and teachers to explore forces, moments and reactions around a rigid beam at equilibrium through practical experimentation with magnetic components and spring balances.
Product Overview
The kit enables comprehensive experiments with rigid beams in multiple support configurations, including simply-supported and balanced beam setups. Students apply forces using masses and magnetic mounts, then measure reaction forces with spring balances to compare against theoretical values derived from equilibrium equations and moment theory. The magnetic bases ensure accurate and easy positioning of all experiment components. Equilibrium of a Beam – FortiTestX – 52 combines hands-on experimentation with visual clarity, making it ideal for classroom demonstrations and small group learning in statics fundamentals.
Equilibrium of a Beam – FortiTestX – 52 — Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | Equilibrium of a Beam – FortiTestX – 52 |
| Beam Type | Rigid beam with hook points |
| Support Configurations | Simply-supported and balanced beam setups |
| Force Application Method | Masses, magnetic mounts, spring balances |
| Force Measurement | Reaction forces via spring balances |
| Base Unit Required | Work Panel (FortiTestX – 53) |
| Attachment System | Magnetic components and hook points |
| Net Weight | 3.7 kg + 1 kg storage tray |
| Packed Volume | Approximately 0.015 m3 |
| Packed Weight | Approximately 6 kg |
| Warranty | Five years |
| Certification | ISO 9001, EU directives compliant |
Technical Data
Operating Conditions
| Parameter | Value |
|---|---|
| Operating Environment | Well lit classroom or laboratory |
| Storage Temperature Range | –25°C to +55°C (when packed for transport) |
| Operating Temperature Range | +5°C to +40°C |
| Operating Relative Humidity | 80% at temperatures < 31°C, decreasing linearly to 50% at 40°C |
Essential Services
| Requirement | Specification |
|---|---|
| Bench/Desktop Dimensions | Minimum 1100 mm wide x 540 mm front to back |
Key Features
- Beam Configuration: Rigid beam with multiple hook points for flexible setup options
- Support Types: Simply-supported and balanced beam configurations for varied experiments
- Force Measurement: Spring balances for accurate reaction force measurement demonstrating equilibrium of a beam
- Magnetic Attachment: Magnetic bases and hook points for precise, stable positioning on Work Panel
- Load Application: Weight hangers with adjustable mass placement for moment and force studies
- Experimental Approach: Hands-on method with visual setup for improved student understanding
- Storage: Hard-wearing storage tray included for safe component organization
- Documentation: Fully illustrated user guide with theory, experiments and typical results
- Warranty: Five-year manufacturer warranty included
Experiments
- Using moments and equilibrium theory to find beam reaction forces and unknown forces
- Simply-supported beam analysis and force distribution
- Balanced beam equilibrium and moment calculations
- Reaction force measurement and comparison with theoretical values
Construction and Design
Equilibrium of a Beam – FortiTestX – 52 comprises a rigid beam with integrated hook points and magnetic attachment components designed for compatibility with the Work Panel (FortiTestX – 53). The apparatus demonstrates equilibrium of a beam through multiple support configurations and adjustable load positioning. Magnetic hook points, spring balances, weight hangers, and lightweight hooks enable rapid reconfiguration for different experimental setups. The robust construction ensures stability during measurements while allowing students to visually observe force distribution and moment effects around the beam.
Scope of Delivery
- Rigid beam with hook points
- Spring balances
- Magnetic hook points
- Lightweight hooks
- Weight hangers and weights
- Comprehensive user guide with theory and experiments
- Storage tray
Required for Operation
- Work Panel (FortiTestX – 53)
- Well lit classroom or laboratory environment
- Level bench or desktop minimum 1100 mm wide x 540 mm front to back
Q: What is equilibrium of a beam?
A: Equilibrium of a beam occurs when all vertical forces and moments acting on the beam are balanced, resulting in zero net force and zero net moment. This kit demonstrates these principles through practical measurement and comparison with theory.
Q: What support configurations can be tested?
A: The apparatus supports both simply-supported beam configurations and balanced beam setups, allowing students to explore different structural scenarios and their effects on reaction forces.
Q: How are forces applied and measured?
A: Forces are applied using adjustable masses and magnetic mounts. Spring balances measure the resulting reaction forces, which students then compare against theoretical values calculated from equilibrium equations.
Q: Can the load position be adjusted?
A: Yes, weight hangers can be positioned at various points along the beam, allowing exploration of how moment and equilibrium of a beam change with load placement.
Q: What warranty is provided?
A: This apparatus includes a five-year warranty and is manufactured in accordance with latest EU directives with ISO 9001 certification.
