The Programmable Logic Control Trainer (Siemens Based) NexuMation-51 is a complete PLC training platform for engineering laboratories, built around the Siemens CPU 1215C with 14 digital inputs, 10 digital outputs, 2 analog inputs, 2 analog outputs, and 125 KB program memory. This programmable logic control trainer supports Ladder, STL, and FBD programming, with built-in digital input simulators (8 toggle, 8 momentary), an analog input simulator, dual Ethernet PC interface, and fixed DC power supplies at 24 V, +12 V, -12 V, and 5 V. All accessories are included for immediate use, and 13 optional control modules extend the platform to industrial automation applications including conveyor, elevator, robot, and HMI control.
The Programmable Logic Control Trainer (Siemens Based) NexuMation-51 is a dedicated PLC training unit built around the Siemens CPU 1215C for hands-on automation education in engineering laboratories. This programmable logic control trainer covers digital and analog I/O, ladder logic, STL, and FBD programming through structured experiments, with built-in digital input simulators, analog voltage sources, and dual Ethernet PC interface. It supports a wide range of optional control modules extending the platform to traffic light, conveyor, elevator, motor, and robot control applications.
Product Overview
The Programmable Logic Control Trainer (Siemens Based) NexuMation-51 addresses the rapidly growing demand for industrial automation training by providing a complete, ready-to-use PLC training platform. The core of the unit is the Siemens CPU 1215C, configured with 14 digital inputs at 24 V DC (source/sink), 10 digital outputs at 24 V DC (source), 2 analog voltage inputs, 2 analog voltage outputs, and 125 KB program memory. Three programming languages are supported: Ladder, STL, and FBD. Built-in digital input simulators provide 8 toggle inputs and 8 momentary inputs for experiment operation without external signal sources. An analog input simulator is also installed. Two analog voltage sources at +10 V each are included. Fixed DC power supplies provide 24 V, +12 V, -12 V, and 5 V rails. PC connectivity is provided via two Ethernet ports. A 40-pin IDC optional module interface header is installed for expansion. This programmable logic control trainer ships with all accessories required for immediate operation, including 2 mm patch cords, a power cord, IDC cable, PLC programming cable (RJ45), software CD, and experiment manual. Thirteen optional control modules extend the platform to real-world automation scenarios including traffic light control, water level control, temperature control, conveyor control, elevator control, motor control, robot control, weight control, HMI integration, and prismatic piece storage and sorting control.
Technical Specifications
| Parameter | Detail |
|---|---|
| Model Reference | NexuMation-51 |
| PLC Model | Siemens CPU 1215C |
| Digital Inputs | 14 x 24 V DC (Source/Sink) |
| Digital Outputs | 10 x 24 V DC (Source) |
| Analog Inputs | 2 x Voltage Type |
| Analog Outputs | 2 x Voltage Type |
| Program Memory | 125 KB |
| Programming Languages | Ladder, STL, FBD |
| Digital Input Simulator | 8 x Toggle Inputs, 8 x Momentary Inputs |
| Analog Input Simulator | Installed |
| Analog Voltage Source | 2 x +10 V |
| Fixed DC Supply | 24 V, +12 V, -12 V, 5 V |
| PC Interface | Ethernet ports x 2 |
| Optional Module Interface | 40-pin IDC connector |
Technical Data
PLC Core
| Parameter | Value |
|---|---|
| PLC Model | Siemens CPU 1215C |
| Digital Inputs | 14 x 24 V DC (Source/Sink) |
| Digital Outputs | 10 x 24 V DC (Source) |
| Analog Inputs | 2 x Voltage Type |
| Analog Outputs | 2 x Voltage Type |
| Program Memory | 125 KB |
| Programming Languages | Ladder, STL, FBD |
Input Simulators
| Parameter | Value |
|---|---|
| Toggle Inputs | 8 |
| Momentary Inputs | 8 |
| Analog Input Simulator | Installed |
Power Supplies
| Rail | Value |
|---|---|
| Fixed DC Supply 1 | 24 V |
| Fixed DC Supply 2 | +12 V |
| Fixed DC Supply 3 | -12 V |
| Fixed DC Supply 4 | 5 V |
| Analog Voltage Source | 2 x +10 V |
Interfaces
| Parameter | Value |
|---|---|
| PC Interface | Ethernet ports x 2 |
| Optional Module Interface | 40-pin IDC connector |
Key Features
- PLC Core: Siemens CPU 1215C with 125 KB program memory
- Digital I/O: 14 x 24 V DC digital inputs (source/sink), 10 x 24 V DC digital outputs (source)
- Analog I/O: 2 x voltage-type analog inputs, 2 x voltage-type analog outputs on this programmable logic control trainer
- Programming Languages: Ladder, STL, and FBD supported simultaneously
- Digital Input Simulators: 8 toggle inputs and 8 momentary inputs installed
- Analog Input Simulator: installed for signal simulation without external sources
- Analog Voltage Source: 2 x +10 V
- Fixed Power Supplies: 24 V, +12 V, -12 V, and 5 V DC rails installed
- PC Interface: dual Ethernet ports for programming and monitoring
- Optional Module Interface: 40-pin IDC header for expansion module connection
- Optional Modules: 13 control modules available including traffic light, conveyor, elevator, motor, robot, HMI, and weight control
Experiments
- Implementation of Logic Gates
- Implementation of Timers
- Implementation of 4-bit Digital to Analog Converter
- Implementation of UP/DOWN Counter
- Implementation of 4-bit Analog to Digital Converter
Construction and Design
The Programmable Logic Control Trainer (Siemens Based) NexuMation-51 is built around the Siemens CPU 1215C PLC module integrated within a self-contained training panel. All power supplies are installed internally, providing 24 V, +12 V, -12 V, and 5 V DC fixed rails alongside two analog voltage sources at +10 V each. Digital input simulation is handled by 8 toggle switches and 8 momentary pushbuttons installed on the panel, with an analog input simulator for voltage signal generation. Two Ethernet ports provide PC connectivity for programming via the included RJ45 PLC programming cable. A 40-pin IDC header is mounted on the panel for direct connection to optional expansion modules. This programmable logic control trainer supports all three IEC 61131-3 compliant programming languages available on the Siemens S7-1200 platform: Ladder, STL, and FBD. The unit ships ready for use with all accessories and experiment manual included. Thirteen optional control modules extend the platform to cover a comprehensive range of industrial automation scenarios.
Optional Modules
- Traffic Light Control by PLC
- Water Level Control by PLC
- Temperature Control by PLC
- Conveyor Control by PLC
- Elevator Control by PLC
- Motor Control by PLC
- Pushbutton Panel
- Robot Control Module by PLC
- Module for Testing Selecting Pieces Control by PLC
- Weight Control Module by PLC
- Storage Control Module for Prismatic Pieces by PLC
- Conveyor Belt Control Module by PLC
- HMI Module
Scope of Delivery
- 1 experimental unit
- 2 mm patch cords
- Power cord
- Experiment manual
- IDC cable
- PLC programming cable (RJ45)
- Software CD
Q1: Which PLC model is used in the Programmable Logic Control Trainer (Siemens Based) NexuMation-51?
The unit is built around the Siemens CPU 1215C, configured with 14 digital inputs, 10 digital outputs, 2 analog inputs, 2 analog outputs, and 125 KB program memory.
Q2: What programming languages does this programmable logic control trainer support?
Three programming languages are supported: Ladder, STL (Statement List), and FBD (Function Block Diagram), consistent with IEC 61131-3 standards for the Siemens S7-1200 platform.
Q3: Are input simulators included, or must external signal sources be connected?
Both digital and analog input simulators are installed on the panel. Digital simulation uses 8 toggle inputs and 8 momentary inputs. An analog input simulator is also built in, enabling all experiments without external signal sources.
Q4: How is the NexuMation-51 connected to a PC for programming?
Two Ethernet ports provide PC connectivity. A PLC programming cable (RJ45) is included in the scope of delivery.
Q5: What optional modules are available for the NexuMation-51?
Thirteen optional modules are available, including traffic light control, water level control, temperature control, conveyor control, elevator control, motor control, robot control, weight control, HMI, pushbutton panel, piece selection testing, conveyor belt control, and prismatic piece storage control.
