Air Flow Impulse Turbine | ThermoFlux – 7095
The Air Flow Impulse Turbine ThermoFlux – 7095 is a standalone table-top unit for investigating a single-stage axial flow impulse turbine driven by compressed air at approximately 6 bar. The turbine delivers a maximum of 200 W, features a 130 mm wheel with 45 blades at a 20° inlet/outlet angle, and is loaded by a belt brake dynamometer. This air flow impulse turbine measures torque (0 to 25 Nm via force sensor), speed (0 to 50,000 rpm via proximity switch), flow rate (25 to 315 ltr/sec), inlet pressure (0 to 10 bar), outlet pressure (0 to 0.5 bar), and temperature (-100 to 400°C), with digital displays for speed, torque, and temperature, and dial manometers for pressure. An optional air compressor (ThermoFlux – 7095) and LabVIEW-based DAQ software are available for continuous operation and PC-based data acquisition.
The Air Flow Impulse Turbine ThermoFlux – 7095 is a standalone table-top laboratory unit designed to enable students to investigate the performance of a single-stage axial flow impulse turbine using compressed air. This air flow impulse turbine is equipped with a belt brake dynamometer, force sensor torque measurement, proximity switch speed measurement, and digital instrumentation for pressure, temperature, mass flow, speed, and torque across a full range of operating conditions.
Product Overview
The Air Flow Impulse Turbine ThermoFlux – 7095 consists of a single-stage axial flow impulse machine with a throttle valve and belt brake dynamometer. In an impulse turbine, the fluid pressure drop and consequent velocity increase occur in the stator, and the fluid passes through the rotor at approximately constant pressure. Compressed air is supplied at approximately 6 bar to drive the turbine.
The turbine delivers a maximum power output of 200 W. The wheel diameter is approximately 130 mm with 45 rotor blades and an inlet/outlet angle of 20°. Turbine loading is applied using a belt brake. Torque is measured by a force sensor over a range of 0 to 25 Nm. Rotational speed is measured by a proximity switch over a range of 0 to 50,000 rpm. Flow rate is measured over a range of 25 to 315 ltr/sec. Inlet pressure is measured from 0 to 10 bar and outlet pressure from 0 to 0.5 bar. Temperature measurement covers -100 to 400°C.
Speed, torque, and temperature are displayed on digital displays. Relevant pressures are shown on dial manometers. An optional air compressor (ThermoFlux – 7095) is available for continuous operation. Optional DAQ software enables PC-based data acquisition in a LabVIEW environment.
Air Flow Impulse Turbine ThermoFlux – 7095 — Technical Specifications
| Parameter | Value |
|---|---|
| Turbine Type | Single-stage, axial flow, impulse |
| Maximum Power Output | 200 W |
| Wheel Diameter | Approx. 130 mm |
| Number of Rotor Blades | 45 |
| Inlet/Outlet Angle | 20° |
| Compressed Air Supply | Approx. 6 bar |
| Loading Method | Belt brake dynamometer |
| Torque Measurement Method | Force sensor |
| Torque Measuring Range | 0 to 25 Nm |
| Speed Measurement Method | Proximity switch |
| Speed Measuring Range | 0 to 50,000 rpm |
| Flow Rate Measuring Range | 25 to 315 ltr/sec |
| Inlet Pressure Measuring Range | 0 to 10 bar |
| Outlet Pressure Measuring Range | 0 to 0.5 bar |
| Temperature Measuring Range | -100 to 400°C |
| Pressure Display | Dial manometers |
| Speed, Torque and Temperature Display | Digital displays |
Technical Data
Turbine
| Parameter | Value |
|---|---|
| Type | Single-stage, axial flow, impulse |
| Maximum Power Output | 200 W |
| Wheel Diameter | Approx. 130 mm |
| Number of Rotor Blades | 45 |
| Inlet/Outlet Angle | 20° |
| Compressed Air Supply | Approx. 6 bar |
| Loading Method | Belt brake dynamometer |
Torque Measurement
| Parameter | Value |
|---|---|
| Method | Force sensor |
| Measuring Range | 0 to 25 Nm |
Speed Measurement
| Parameter | Value |
|---|---|
| Method | Proximity switch |
| Measuring Range | 0 to 50,000 rpm |
Flow Rate Measurement
| Parameter | Value |
|---|---|
| Measuring Range | 25 to 315 ltr/sec |
Pressure Measurement
| Parameter | Value |
|---|---|
| Inlet Pressure Range | 0 to 10 bar |
| Outlet Pressure Range | 0 to 0.5 bar |
| Display Type | Dial manometers |
Temperature Measurement
| Parameter | Value |
|---|---|
| Measuring Range | -100 to 400°C |
| Display | Digital |
Key Features
- Air Flow Impulse Turbine Type: Single-stage, axial flow, impulse machine with throttle valve
- Maximum Power Output: 200 W
- Compressed Air Supply: Approx. 6 bar
- Wheel Diameter: Approx. 130 mm
- Number of Rotor Blades: 45
- Inlet/Outlet Blade Angle: 20°
- Turbine Loading: Belt brake dynamometer
- Torque Measurement: Force sensor, 0 to 25 Nm
- Speed Measurement: Proximity switch, 0 to 50,000 rpm
- Flow Rate Measurement: 25 to 315 ltr/sec
- Inlet Pressure Measurement: 0 to 10 bar, dial manometer
- Outlet Pressure Measurement: 0 to 0.5 bar, dial manometer
- Temperature Measurement: -100 to 400°C, digital display
- Display: Speed, torque, and temperature on digital displays; pressures on dial manometers
- Unit Format: Standalone table-top unit
- Optional Accessory: Air Compressor ThermoFlux – 7095 for continuous operation
- Software: Optional LabVIEW-based DAQ software, Windows compatible
Experiments
- Determination of power as a function of volumetric flow rate, pressure, and speed
- Recording of torque characteristic
- Determination of turbine efficiency
- Partial pressurization (nozzle group circuit)
Construction and Design
The Air Flow Impulse Turbine ThermoFlux – 7095 is a standalone table-top unit built around a single-stage axial flow impulse machine with a throttle valve. The turbine wheel has a diameter of approximately 130 mm, carries 45 rotor blades, and operates with an inlet/outlet angle of 20°. Compressed air is supplied at approximately 6 bar. A belt brake dynamometer applies the load to the turbine shaft. A force sensor measures torque from 0 to 25 Nm. A proximity switch measures rotational speed from 0 to 50,000 rpm. Flow rate measurement covers 25 to 315 ltr/sec. Inlet pressure is measured from 0 to 10 bar and outlet pressure from 0 to 0.5 bar, both displayed on dial manometers. Temperature measurement covers -100 to 400°C with digital display. Speed, torque, and temperature readings are shown on dedicated digital displays. This air flow impulse turbine delivers a maximum power output of 200 W and supports optional PC-based data acquisition via LabVIEW DAQ software when connected to a separate compressor.
Software
ThermoFlux – 7095 Software (Optional)
- Developed in the National Instruments LabVIEW environment
- Designed specifically for data acquisition with this apparatus
- Measures, processes, and stores experimental results on a PC
- A set of electronic sensors is included when the software option is selected
- Compatible with any Windows operating system
Scope of Delivery
- 1 experimental unit
- 1 set of hoses
- 1 instructional manual
Optional Accessories
| Item | Model |
|---|---|
| Air Compressor for Continuous Operation | Air Compressor ThermoFlux – 7095 |
Q1: What type of turbine is used in the Air Flow Impulse Turbine ThermoFlux – 7095?
The unit uses a single-stage axial flow impulse turbine. In this configuration, the fluid pressure drop and velocity increase occur in the stator, and the fluid passes through the rotor at approximately constant pressure.
Q2: What are the key turbine performance parameters of this air flow impulse turbine?
The turbine delivers a maximum power output of 200 W. The wheel diameter is approximately 130 mm with 45 rotor blades, an inlet/outlet angle of 20°, and is supplied with compressed air at approximately 6 bar.
Q3: How is turbine torque and speed measured?
Torque is measured by a force sensor over a range of 0 to 25 Nm. Speed is measured by a proximity switch over a range of 0 to 50,000 rpm. Both values are shown on dedicated digital displays.
Q4: How are pressures displayed on the unit?
Inlet pressure (0 to 10 bar) and outlet pressure (0 to 0.5 bar) are displayed on dial manometers. Speed, torque, and temperature readings are shown on digital displays.
Q5: Is a compressor included with the unit?
No. Compressed air is supplied from a separate compressor. An optional air compressor suitable for continuous operation (Air Compressor ThermoFlux – 7095) is available as an accessory.
