Study of Fuel Injection Systems Trainer | Thermoflux 12098
The Study of Fuel Injection Systems Trainer Thermoflux 12098 demonstrates inline pump, rotary pump, and CRDI diesel injection systems. This fuel injection systems trainer features sectioned or working models with labeled components on a rigid fabricated frame, supporting classroom study of construction, working principles, and injection characteristics.
The Study of Fuel Injection Systems Trainer Thermoflux 12098 is a demonstration unit for studying diesel fuel injection technologies. This fuel injection systems trainer covers inline pump, rotary pump, and CRDI systems for IC engine laboratories.
Product Overview
The Thermoflux 12098 fuel injection systems trainer includes sectioned or working models of an inline fuel injection pump, a rotary (distributor) fuel injection pump, and a common rail direct injection (CRDI) system. Internal components and fuel flow are visible for classroom study. The trainer also covers fuel injection characteristics. It is mounted on a heavy duty fabricated structure with labeled components.
Study of Fuel Injection Systems Trainer Thermoflux 12098 — Technical Specifications
| Parameter | Value |
|---|---|
| Trainer Type | Demonstration and study model |
| Systems Covered | Inline pump, rotary pump, CRDI |
| Mounting | Heavy duty fabricated structure |
| Operation | Manual / demonstrative |
| Components | Labeled |
| Application | IC engine and automobile labs |
Technical Data
Systems:
- Inline fuel injection pump
- Rotary (distributor) fuel injection pump
- CRDI (common rail direct injection) system
- Fuel injection characteristics study
Structure:
- Rigid frame mounted trainer
- Heavy duty fabricated mounting
Key Features
- Multi-System Demonstration: Inline, rotary, and CRDI systems in one trainer
- Visible Internals: Sectioned or working models show construction and fuel flow
- Labeled Components: Clear identification for classroom instruction
- Rigid Frame: Heavy duty fabricated structure for repeated use
- Low Maintenance: Designed for long service life and academic use
- Customizable: Built to suit curriculum requirements
Experiments
- Construction study of inline fuel injection pump
- Working principle study of rotary fuel injection pump
- Operation study of CRDI system
- Functional comparison of conventional and modern diesel injection systems
- Fuel injection characteristics study
Construction and Design
The Thermoflux 12098 trainer uses a heavy duty fabricated structure with a rigid frame. Sectioned or working models of the inline pump, rotary pump, and CRDI system are mounted with labeled components. Internal parts and fuel flow are visible for demonstration.
Scope of Delivery
- 1 Study of fuel injection systems trainer
- 1 Set of labeled models (inline pump, rotary pump, CRDI system)
Q: Which fuel injection systems does the Thermoflux 12098 trainer cover?
A: It covers the inline fuel injection pump, rotary (distributor) fuel injection pump, and CRDI (common rail direct injection) system.
Q: Who is the Thermoflux 12098 trainer designed for?
A: It is designed for mechanical engineering, automobile engineering, and IC engine laboratories at academic institutions.
Q: Is the Thermoflux 12098 trainer customizable?
A: Yes. Customization is available to match curriculum requirements.
