Cut Section Model of Four Stroke Petrol Engine | Torquemaster-34
Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 is carefully sectioned to reveal internal constructional details and demonstrate the working of valves, pistons, pumps, crank and camshaft. Built by a specialist Cut Section Model of Four Stroke Petrol Engine Manufacturer, this dissectible model has a 160cc displacement, 6 hp power output, overhead valves, and a camshaft in the crankcase, along with an rpm regulator, oil pump, carburetor, air filter, silencer and tank. It is manually operated through a crank handle, mounted on a sturdy iron frame with flywheel, and weighs approximately 35kg.
The Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 is carefully sectioned for training purposes, professionally painted with different colours to better differentiate the various parts, cross-sections, lubricating circuits, fuel system, and cooling system. As an experienced Cut Section Model of Four Stroke Petrol Engine Manufacturer, SCIENTICO chromium-plates and galvanizes many parts for a longer life.
Product Overview
The Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 is sectioned to show internal constructional details. The working of individual parts and accessories like valves, pistons, pumps, crank and camshaft is demonstrated. It is provided with a flywheel and mounted on a sturdy iron frame. This actual cut section engine helps students understand the parts and working of the engine very easily. It is specially made dissectible for demonstration purposes. The actual cut section engine is supplied with a key card and interesting literature regarding its working. As a trusted Cut Section Model of Four Stroke Petrol Engine Manufacturer, SCIENTICO ensures fine finish, simple operation, and functional accuracy in every unit.
Planning an automobile lab? See the automobile engineering equipment and model-selection guide.
Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 — Technical Specifications
| Parameter | Value |
|---|---|
| Operation | Manually operated (through a crank handle) |
| Equipment Layout | On base |
| Finish | Fine finish |
| Operation Type | Simple operations |
| Accuracy | Functional accuracy |
| Displacement | 160cc |
| Power | 6 hp |
| Camshaft | In the crankcase |
| Valves | Overhead valves |
| Speed Control | Rpm regulator |
| Lubrication | Oil pump |
| Fuel System | Carburetor |
| Air Filter | Included |
| Silencer | Included |
| Tank | Included |
| Length | 500 mm (approx.) |
| Width | 500 mm (approx.) |
| Height | 600 mm (approx.) |
| Weight | 35kg (approx.) |
Technical Data
Engine Specification
| Parameter | Value |
|---|---|
| Displacement | 160cc |
| Power | 6 hp |
| Camshaft Location | In the crankcase |
| Valve Type | Overhead valves |
Auxiliary Systems
| Parameter | Value |
|---|---|
| Rpm Regulator | Included |
| Oil Pump | Included |
| Carburetor | Included |
| Air Filter | Included |
| Silencer | Included |
| Tank | Included |
Operation
| Parameter | Value |
|---|---|
| Method | Manual, through crank handle |
| Layout | On base |
Dimensions and Weight
| Parameter | Value |
|---|---|
| Length | 500 mm (approx.) |
| Width | 500 mm (approx.) |
| Height | 600 mm (approx.) |
| Weight | 35kg (approx.) |
Key Features
- Operation: Manually operated through a crank handle
- Layout: Equipment mounted on base
- Finish: Fine finish with functional accuracy
- Ease of Use: Simple operations
- Displacement: 160cc
- Power Output: 6 hp
- Camshaft Position: In the crankcase
- Valve Type: Overhead valves
- Speed Control: Rpm regulator
- Lubrication System: Oil pump
- Fuel Delivery: Carburetor
- Air Filtration: Air filter included
- Noise Reduction: Silencer included
- Fuel Storage: Tank included
- Mounting: Flywheel provided, mounted on sturdy iron frame
- Documentation: Supplied with key card and literature on working
- Manufacturing Standard: Built by a leading Cut Section Model of Four Stroke Petrol Engine Manufacturer for practical engine training
Construction and Design
The Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 is sectioned to show internal constructional details. It is professionally painted with different colours to differentiate parts, cross-sections, lubricating circuits, fuel system, and cooling system. Many parts have been chromium-plated and galvanized for a longer life. The working of individual parts and accessories, including valves, pistons, pumps, crank and camshaft, is demonstrated. A flywheel is provided, and the model is mounted on a sturdy iron frame. The engine is specially made dissectible for demonstration purposes. It is supplied with a key card and literature regarding its working. The engine has a displacement of 160cc and a power output of 6 hp. The camshaft is located in the crankcase, and the valves are overhead type. An rpm regulator, oil pump, carburetor, air filter, silencer and tank are included. The unit is operated manually through a crank handle and laid out on a base. As a dedicated Cut Section Model of Four Stroke Petrol Engine Manufacturer, SCIENTICO India builds this construction to combine fine finish, simple operation and functional accuracy for effective classroom demonstration.
Q: What is the Cut Section Model of Four Stroke Petrol Engine Torquemaster-34 used for?
A: It is used to demonstrate internal constructional details and the working of individual parts and accessories such as valves, pistons, pumps, crank and camshaft in a four stroke petrol engine.
Q: What is the displacement and power of the engine?
A: Displacement is 160cc and power is 6 hp.
Q: How is the engine model operated?
A: It is operated manually through a crank handle, with equipment layout on base.
Q: What auxiliary systems are included?
A: Rpm regulator, oil pump, carburetor, air filter, silencer, and tank.
Q: What are the dimensions and weight of the model?
A: L x W x H (approx.): 500 x 500 x 600 mm, weight (approx.): 35kg.
