Electrical and Electronic Component Training Kit | SC-EEK 1084
Electrical and Electronic Component Training Kit SC-EEK 1084 is a trainer box of 4 mm male-ended component carriers. The carriers plug into experimenter board Item 11085 and show each circuit symbol and value. The kit includes switches, lamps, LEDs, resistors, potentiometers, capacitors, semiconductors, and coils. It is stored in a compartmented case with printed inventory and includes course software with a room licence.
Electrical and Electronic Component Training Kit SC-EEK 1084 is a trainer box of 4 mm male-ended component carriers. The carriers plug directly into experimenter board Item 11085.
Product Overview
The Electrical and Electronic Component Training Kit SC-EEK 1084 includes switches, pushbuttons, lamps, LEDs, resistors, potentiometers, capacitors, semiconductors, and coils. Each carrier shows the circuit symbol and value. The kit includes a compartmented case with printed inventory.
Electrical and Electronic Component Training Kit SC-EEK 1084: Technical Specifications
| Parameter | Specification |
|---|---|
| Model No. | SC-EEK 1084 |
| Brand / Origin | Scientico® / India |
| Carrier Type | 4 mm male-ended component carriers |
| Compatible Board | Experimenter board Item 11085 |
| Switching / Indication | 5 switches; 5 pushbuttons; 5 incandescent lamps; 5 red LEDs; 5 green LEDs |
| Resistors | 50 resistors, 33 ohm to 1 Mohm, 0.5 W / 1 W / 2 W |
| Potentiometers | 2 each of 1 k, 10 k, 47 k, 100 k, 470 kohm |
| Capacitors | 5 x 0.1 µF; 5 x 22 µF; 5 x 0.47 µF; 5 x 1 µF; electrolytic 2 x 1 µF, 5 x 10 µF, 5 x 100 µF, 5 x 470 µF |
| Semiconductors | 10 x 1N4007; 1 x AA118 germanium diode; Zener 4.7 V and 10 V; 2 x BC547; 2 x BD237; 2 x 2N3819; 2 x BS170; 2 diacs; 2 thyristors; 2 triacs; 2 x LM741 |
| Coils | 2 each of 10, 33, 50, 100 mH; transformer coils N = 300 and N = 900 |
| Storage | Compartmented case with printed inventory |
Key Features
- Carrier Type: 4 mm male-ended, plug-in
- Labeling: circuit symbol and value on each carrier
- Training Kit: Electrical and Electronic Component Training Kit SC-EEK 1084 for experimenter board Item 11085
- Switching: 5 switches, 5 pushbuttons
- Indication: 5 incandescent lamps, 5 red LEDs, 5 green LEDs
- Resistors: 50 pieces, 33 ohm to 1 Mohm
- Semiconductors: 10 x 1N4007, BC547, BD237, LM741
- Power Devices: 2 thyristors, 2 triacs, 2 diacs
- Storage: compartmented case with printed inventory
- Software: room licence, no recurring fee
Experiments
- Resistor colour code and value verification
- RC charging and discharge with 0.1 µF to 1 µF capacitors
- Diode forward bias characteristics using 1N4007
- Zener voltage regulation at 4.7 V and 10 V
- BC547 transistor switching of LEDs and lamps
- Op-amp LM741 inverting amplifier circuit
- Potentiometer voltage division using 1 k to 470 kohm values
Construction and Design
Electrical and Electronic Component Training Kit SC-EEK 1084 is a trainer box of 4 mm male-ended component carriers. Each carrier plugs into experimenter board Item 11085. Each carrier shows the circuit symbol and value. The kit is stored in a compartmented case with printed inventory.
Software
Course software and browser on media. Room licence, no recurring fee.
Scope of Delivery
- Component kit in storage case
- Media with course software and browser (room licence, no recurring fee)
- English manual and exercises
What does each component carrier show?
Each carrier shows the circuit symbol and value.
Which board do the carriers plug into?
The carriers plug directly into experimenter board Item 11085.
Is the software licence recurring?
No. The media includes a room licence with no recurring fee.
Is a manual included?
Yes. An English manual and exercises are included.
