Temperature Control Training System (Modular Type)

Model NexuMation 66

The Temperature Control Training System (Modular Type) NexuMation 66 is a modular trainer on a vertical two-level frame. This temperature control training system supports two-position, three-range, and PID temperature control up to 100°C. PID ranges are Kp = 0 … 1000, TI = 1ms … 100s, and TD = 0.2ms … 20s. A USB DAQ system and management software are included.

The Temperature Control Training System (Modular Type) NexuMation 66 is designed for the study of temperature control application. This temperature control training system gives students practical training through guided experiments. Industrial type components are educationally adapted using a modular panel system.

Product Overview

The Temperature Control Training System (Modular Type) NexuMation 66 has a modular structure. Educational panels are installed on a vertical frame. A theoretical and practical manual is supplied.

The modular panel system permits step-by-step assembling. Students build from the simplest circuit to the most complex system. This gives a direct and immediate approach to temperature control topics.

The temperature control training system supports two-position, three-range, and PID temperature control. It includes a computerized DAQ system via USB and management software.

emperature Control Training System (Modular Type) NexuMation 66: Technical Specifications

Parameter Value
Structure Modular, educational panels on vertical frame
Work Frame Two-level
Controllers PID, two position, three-range
Power Supply +15 V; 0 V; -15 V, 2.4 A (3 A short period)
PID Range Kp = 0 … 1000, TI = 1ms … 100s, TD = 0.2ms … 20s
Simulated Controlled System Kp = 0.2 … 1.5, T1 = 0.1 … 1000s, T2 = 0.1 … 1000s
Power Amplifier 30 W max., short-circuit protected
Temperature Control System Max. 100°C, feedback 2 mA/10°C or 1 V/10°C
Data Acquisition Computerized DAQ system via USB
Software Management software
Documentation Theoretical and practical manual

Technical Data

Module Specification
DC Power Supply +15 V; 0 V; -15 V. 2.4 A (3 A short period). Single-phase mains. Two LEDs for nominal voltage. Mains switch with pilot lamp
Voltage Reference Generator +15 V; 0 V; -15 V. Continuous and step reference signal: -10 V to +10 V, 0 to +10 V. Switch: internal/external reference. Switch: 0/±10 V or 0/+10 V range
PID Controller +15 V; 0 V; -15 V. Signal range -10V … +10V. Kp = 0 … 1000. TI = 1ms … 100s. TD = 0.2ms … 20s. Continuously adjustable, coarse/fine adjustment. Reset input, Input IOff. Output summing node for noise variables. Error signal measurement terminal. Output offset adjustment. Three LED deviation indicators. Over-range LED above 10 V or below -10 V
Summing Point 5 Inputs +15 V; 0 V; -15 V. Signal range -10V … +10V. Gain factor 1. LED indicator of over-range
Simulated Controlled System +15 V; 0 V; -15 V. Input summing point for controlling variable (y) and noise variable (z). Signal range -10V … +10V. Kp = 0.2 (attenuation) … 1.5 (amplification). T1 = 0.1 … 1000s. T2 = 0.1 … 1000s. Reset input for initial conditions. Coarse rotary switches, potentiometer fine setting. LED indicators of over-range
Manual / Automatic Switch +15 V; 0 V; -15 V. Signal range -10V … +10V. Manual/Automatic mode switch. Manual mode potentiometer. Output summing point
Two Position Controller +15 V; 0 V; -15 V. Input summing point. Signal range -10V … +10V. Output voltages 0/+5 V; 0/+10 V. Adjustable hysteresis 0 … ±2.5 V
Power Amplifier +15 V; 0 V; -15 V. Signal range -10V … +10V. Output voltage -10 V … +10 V to ground; 0 … ±20 V symmetrically. Max. output power 30 W, short-circuit protected
Temperature Control System +15 V; 0 V; -15 V. Max. temperature 100°C. Bimetallic safety switch intervention 90 … 100°C. Feedback signal 2 mA/10°C or 1 V/10°C. Apparent dead time TU about 10s. Compensation time TG about 120s
Single Pole Pushbutton Plug-in element, switch load 2 A, 250 V
Single Pole Switch Plug-in element, normally open, switch load 2 A, 250V

Key Features

  • Structure: modular panels on vertical frame
  • Application: temperature control training system for guided experiments
  • Work Frame: two-level
  • Controllers: PID, two position, three-range
  • PID Parameters: Kp = 0 … 1000, TI = 1ms … 100s, TD = 0.2ms … 20s
  • Power Supply: +15 V; 0 V; -15 V, 2.4 A
  • Power Amplifier: 30 W max., short-circuit protected
  • Temperature Process: max. 100°C, feedback 2 mA/10°C or 1 V/10°C
  • Data Acquisition: computerized DAQ system via USB
  • Software: management software included

Experiments

  • The two-position controller in the temperature process
  • The two-position controller with delayed feedback in the temperature process
  • The two-position controller with elastic feedback in the temperature process
  • The three-range controller in the temperature process
  • P, PI and PID controls of the temperature process using the CHR method

Construction and Design

The Temperature Control Training System (Modular Type) NexuMation 66 is built on a vertical frame. Educational panels are installed in a modular arrangement. A two-level work frame organizes the components.

Industrial type components are educationally adapted. The modular panel system permits step-by-step assembly. Students progress from the simplest circuit to the most complex system.

The temperature control training system includes a temperature control system module with a max. temperature of 100°C and a bimetallic safety switch. A simulated controlled system, controller, and switch modules plug into the frame. A connecting leads set is supplied for interconnection.

A computerized DAQ system connects via USB. Management software runs the experiments.

Software

  • Computerized DAQ system via USB
  • Management software

Scope of Delivery

  • DC Power Supply
  • Voltage Reference Generator
  • PID Controller
  • Summing Point 5 Inputs
  • Simulated Controlled System
  • Manual / Automatic Switch
  • Two Position Controller
  • Power Amplifier
  • Temperature Control System
  • Single Pole Pushbutton
  • Single Pole Switch
  • Computerized DAQ system via USB
  • Management software
  • Connecting Leads Set
  • Two-level work frame
  • Theoretical and practical manual

Q1. What is the Temperature Control Training System (Modular Type) NexuMation 66 designed for?
It is designed for the study of temperature control application through guided experiments.

Q2. Which controllers are included in this temperature control training system?
Two-position, three-range, and PID controllers.

Q3. What are the PID controller ranges?
Kp = 0 … 1000, TI = 1ms … 100s, and TD = 0.2ms … 20s.

Q4. What is the max. temperature of the temperature control system?
100°C, with a bimetallic safety switch intervening at 90 … 100°C.

Q5. How does the temperature control training system connect to a computer?
A computerized DAQ system via USB is included, with management software.
