Free & Damped Torsional Vibration Apparatus | Vibrano X – 07
The Free & Damped Torsional Vibration Apparatus – Vibrano X – 07 studies natural frequency and damping behavior in torsional vibration systems. It includes 3 stainless steel torsion bars (3mm, 5mm, 6mm diameter, 800mm length) and 2 weight discs. This Free & Damped Torsional Vibration Apparatus features an adjustable ball bearing chuck, an open oil filled damper, and an exciter unit for forced vibration. It serves as a supplementary experiment to the universal vibration system.
The Free & Damped Torsional Vibration Apparatus – Vibrano X – 07 experimental set includes three different torsion bars and two different mass discs. An oil damper makes it possible to reduce the amplitude. This Free & Damped Torsional Vibration Apparatus is a supplementary experiment to the universal vibration system.
Product Overview
The experimental set includes three different torsion bars and two different mass discs. An oil damper makes it possible to reduce the amplitude. The components are accurately placed in slots of the frame on the vibration system.
This Free & Damped Torsional Vibration Apparatus is a supplementary experiment to the universal vibration system. It includes 3 torsion bars, 2 weight discs, an adjustable ball bearing chuck, an open oil filled damper, and an exciter unit for forced vibration.
Free & Damped Torsional Vibration Apparatus – Vibrano X – 07, Technical Specifications
| Specification | Detail |
|---|---|
| Application | Supplementary experiment to the universal vibration system |
| Torsion Bars | 3 torsion bars |
| Weight Discs | 2 weight discs |
| Chuck | Adjustable ball bearing chuck |
| Damper | Open oil filled damper |
| Exciter | Exciter unit for forced vibration |
Technical Data
Torsion Bars (Made of Stainless Steel)
| Parameter | Value |
|---|---|
| Diameter | 3mm, 5mm, 6mm |
| Length | 800mm |
Weight Discs
| Parameter | Value |
|---|---|
| Small | D=150mm at approx. 2.7kg |
| Large | D=228mm at approx. 4.8kg |
Chuck
| Parameter | Value |
|---|---|
| Diameter | D=0.5…8.0mm |
Key Features
- Core Function: this Free & Damped Torsional Vibration Apparatus studies natural frequency and damping behavior of torsional vibration
- Torsion Bars: stainless steel, 3 bars, diameters 3mm, 5mm, 6mm, length 800mm
- Weight Discs: 2 discs, small D=150mm at approx. 2.7kg, large D=228mm at approx. 4.8kg
- Chuck: adjustable ball bearing chuck, D=0.5…8.0mm
- Damping: open oil filled damper reduces amplitude
- Forced Vibration: exciter unit included for forced vibration testing
- Component Mounting: components accurately placed in slots of the frame on the vibration system
- System Integration: supplementary experiment to the universal vibration system
- Optional Upgrade: LabVIEW based DAQ software available for measurement and calculation
Experiments
- Natural frequency of torsional vibration
- Effect of torsional stiffness, rotating mass and damping
- Effect of rotating mass, torsional rigidity and damping factor on the behaviour of a rotary oscillator
Construction and Design
The Free & Damped Torsional Vibration Apparatus – Vibrano X – 07 is built around three torsion bars made of stainless steel and two mass discs. The components are accurately placed in slots of the frame on the vibration system. An adjustable ball bearing chuck holds the torsion bars in place, with a diameter range of D=0.5…8.0mm. An open oil filled damper is fitted to reduce vibration amplitude. An exciter unit is included to generate forced vibration for testing. This Free & Damped Torsional Vibration Apparatus is designed as a supplementary experiment to the universal vibration system.
Software
Software Vibrano X – 07 (optional)
DAQ software specially designed in National Instrument™, LabVIEW™ environment to measure and calculate the results of the apparatus. The software is optional. While using the software, a set of electrical vibration sensors with clamping set is included. The software can be run with any Windows™ environment.
Scope of Delivery
- 1 experimental module
- 1 set of rods
- 1 set of disc
- 1 measuring scale
- 1 stopwatch
- 1 thread
- 1 instruction manual
Q: What does the Free & Damped Torsional Vibration Apparatus – Vibrano X – 07 study?
A: It studies the natural frequency of torsional vibration and the effect of torsional stiffness, rotating mass, and damping on a rotary oscillator.
Q: How many torsion bars and weight discs are included?
A: The set includes 3 torsion bars and 2 weight discs.
Q: What are the dimensions of the weight discs?
A: The small disc is D=150mm at approx. 2.7kg, and the large disc is D=228mm at approx. 4.8kg.
Q: How is vibration amplitude reduced in this apparatus?
A: An open oil filled damper is used to reduce the amplitude.
Q: Is data acquisition software available for this apparatus?
A: Yes, the optional Software Vibrano X – 07 is a LabVIEW based DAQ system that runs on any Windows™ environment and includes electrical vibration sensors with a clamping set when selected.
