The Energy Losses in Pipe Apparatus FluidoSurge-X 148 is designed for studying friction and local losses in pipe flow. It enables measurement of pressure losses for laminar and turbulent conditions. The setup includes multiple pipe fittings and a manometer bank for detailed analysis. It operates with a hydraulic bench or laboratory water supply and is suitable for fluid mechanics laboratories.
The Energy Losses in Pipe Apparatus FluidoSurge-X 148 is designed for experimental investigation of head losses in pipe flow. It enables measurement of pressure losses under laminar and turbulent flow conditions. The apparatus supports studies on frictional losses and losses due to fittings and valves. It is suitable for fluid mechanics laboratory teaching and practical experimentation.
Product Overview
The SCIENTICO Energy Losses in Pipe Apparatus FluidoSurge-X 148 provides a clearly arranged experimental setup for studying pipe friction and local losses. Water is supplied either from a hydraulic bench or directly from laboratory mains and flows through various pipe sections and fittings. Pressure losses are measured using multiple pressure tapings connected to a manometer bank. The system allows comparison of losses in straight pipes, bends, contractions, enlargements, and valves under different flow regimes.
| Parameter | Specification |
|---|---|
| Model | FluidoSurge-X 148 |
| Type | Energy Losses in Pipe Apparatus |
| Application | Pipe Friction and Loss Measurement |
| Pipe Inner Diameter | 17 mm |
| Pipe Outer Diameter | 21 mm |
| Enlargement Pipe Inner Diameter | 26 mm |
| Enlargement Pipe Outer Diameter | 32 mm |
| Contraction Diameter | 17 mm |
| Pipe Fittings | 45° elbow, 90° elbow, sharp bend, small bend |
| Flow Regimes | Laminar and turbulent |
| Pressure Measurement | 12 tube water manometer bank |
| Manometer Range | Up to 300 mm WC |
| Pressure Gauges | 2 units |
| Mounting | Bakelite base on aluminum frame |
| Operation Requirement | Hydraulic bench or laboratory water supply |
Key Features-
-
Experimental setup for studying pipe friction losses
-
Measurement of losses in laminar and turbulent flow regimes
-
Investigation of pressure losses in bends, elbows, contractions, and enlargements
-
Manometer bank for simultaneous pressure drop measurement
-
Determination of simple valve characteristics
-
Compatible with hydraulic bench or direct laboratory water connection
Applications-
-
Measurement of pressure loss in straight pipes
-
Study of losses due to bends, elbows, and fittings
-
Determination of losses at contraction and enlargement sections
-
Evaluation of critical Reynolds number
-
Fluid mechanics and hydraulics laboratory experiments
Construction & Design Details-
The apparatus is mounted on a rigid aluminum structure with a Bakelite base to ensure stability during experiments. Pipe sections and fittings are arranged on a training panel for clear visibility and ease of operation. Pressure tapings are provided at strategic locations and connected to a multi tube manometer bank for accurate pressure measurement. The layout allows individual investigation of different components without system reconfiguration.
Export & Supply Capability-
SCIENTICO manufactures the Energy Losses in Pipe Apparatus FluidoSurge-X 148 for domestic and international supply. The unit is suitable for export to engineering colleges, universities, and technical training laboratories. Standard packing, hose piping, and documentation are provided with each unit.
Q1. What types of losses can be studied using this apparatus?
It allows study of frictional losses in pipes and local losses due to bends, fittings, contractions, enlargements, and valves.
Q2. Can both laminar and turbulent flows be investigated?
Yes, the apparatus supports experiments in both laminar and turbulent flow regimes.
Q3. How are pressure losses measured?
Pressure losses are measured using pressure tapings connected to a multi tube water manometer bank.
Q4. Is a hydraulic bench mandatory for operation?
No, the apparatus can operate with either a hydraulic bench or a laboratory water connection.
Q5. What measuring instruments are included?
A 12 tube water manometer bank and two pressure gauges are included for pressure measurement.
